| SIZE | d | D | D1 | D2 | C | t | L | H | W | A | B | R | r | K*K | h | N-Øz |
| 1/2" | 15 | 95 | 65 | 45 | 14 | 2 | 130 | 51 | 140 | 50 | 36 | 3.5 | 3 | 9*9 | 9 | 4-Ø14 |
| 3/4" | 20 | 105 | 75 | 55 | 14 | 2 | 140 | 56 | 140 | 50 | 36 | 3.5 | 3 | 9*9 | 9 | 4-Ø14 |
| 1" | 25 | 115 | 85 | 65 | 14 | 2 | 150 | 62 | 170 | 70 | 50 | 4.5 | 3.5 | 11*11 | 11 | 4-Ø14 |
| 11/4" | 32 | 135 | 100 | 78 | 16 | 2 | 165 | 72 | 170 | 70 | 50 | 4.5 | 3.5 | 11*11 | 11 | 4-Ø18 |
| 11/2" | 40 | 145 | 110 | 85 | 16 | 3 | 180 | 78 | 200 | 70 | 50 | 4.5 | 3.5 | 14*14 | 14 | 4-Ø18 |
| 2" | 50 | 160 | 125 | 100 | 16 | 3 | 200 | 86 | 200 | 70 | 50 | 4.5 | 3.5 | 14*14 | 14 | 4-Ø18 |
| 21/2" | 65 | 180 | 145 | 120 | 18 | 3 | 220 | 102 | 300 | 102 | 70 | 5.5 | 4.5 | 17*17 | 17 | 8-Ø18 |
| 3" | 80 | 195 | 160 | 135 | 20 | 3 | 250 | 115 | 300 | 102 | 70 | 5.5 | 4.5 | 17*17 | 17 | 8-Ø18 |
| 4" | 100 | 215 | 180 | 155 | 20 | 3 | 280 | 137 | 300 | 102 | 70 | 5.5 | 4.5 | 17*17 | 17 | 8-Ø18 |
| 5" | 125 | 245 | 210 | 188 | 22 | 3 | 320 | 175 | 650 | 125 | 102 | 7 | 6 | 22 | 23 | 8-Ø18 |
| 6" | 150 | 280 | 240 | 212 | 24 | 3 | 360 | 208 | 800 | 125 | 102 | 7 | 6 | 27 | 28 | 8-Ø22 |
| 8" | 200 | 335 | 295 | 268 | 26 | 3 | 400 | 252 | 800 | 140 | 125 | 9 | 7 | 27 | 28 | 12-Ø22 |
